Dosing pumps can be called a type of pump that provides automatic dosing of certain chemicals for different purposes. In these pumps, which can also be called electronically operated electromagnetic dosing pumps, the flow is provided by the movement of the diaphragm. With the impulse coming from the electronic circuit, the magnet pulls the diaphragm piston and thus maximum stroke occurs, the diaphragm connected to the steel core pushes the solution to the pump head.
The suction check valve at the suction port closes, the discharge check valve at the discharge port opens and the solution is pressed into the discharge hose. After the magnetization is completed, the suction check valve opens and the discharge check valve closes, thus the liquid is drawn into the pump head. Frequency adjustment should be made slowly. As a result, the dosing process is carried out thanks to the dosing pump.
Chlorine Dosing
INJECTA Dosing Pumps; acid, chlorine, liquid fertilizer, etc. They are precision dosing devices designed to be used in places where chemicals need to be dosed (pools, drinking water, agricultural irrigation, etc.).
Chlorine dosing pump usage area is very common. Sodium hypochlorite solution prepared for drinking water and process water disinfection, for dosing calcium hypochlorite solutions suitable for drinking water disinfection applications; They are used for dosing dichlorine solutions preferred for pool water disinfection.
Chlorine Dosing Pump Selection
When choosing a Chlorine Dosing Pump, the daily and hourly amount (flow rate) of the water to be dosed with chlorine and the pressure values ??on the line where chlorine dosing will be done should be known. It is possible to do chlorine dosage from different points. It is possible to do chlorine dosage in the water pipeline going to the water tank, in the water tank or directly on the line. The most important factor to consider when dosing chlorine is to ensure sufficient waiting time. A certain waiting period is required for the dosed chlorine to provide the necessary disinfection and kill germs. When processing with chlorine, 0.30.6 ppm chlorine is required in drinking water in accordance with TS266. In pools, the standards of the Ministry of Health are 1-3 ppm chlorine.
General Features of Chlorine Dosing Pump
- Design whose stroke speed can be adjusted between 0 - 100% with the potentiometer on it
- Easy and flexible installation and use thanks to its vertically mounted design
- Full plastic body providing high resistance to corrosive chemicals
- Controlled by electronic circuit electromagnet and long-lasting teflon (PTFE) diaphragm
- Less maintenance thanks to ceramic ball design
- Compression and suction accessories
