What is a Brazed Plate Heat Exchanger? - Applications and Structure
MIT Brazed Plate Exchangers can be designed with different plates offering distinct heat transfer properties. Generally used in processes where tightness is crucial, as the name suggests, the plates in these exchangers are brazed together. With fewer moving parts, they have a structure more resistant to corrosion, pressure, and temperature. The general structure of brazed exchangers, which can be chosen from three different plate types according to the need, is as shown in the diagram below.
Structure of Brazed Exchangers;
MIT Brazed Plate Heat Exchangers can be designed with different plates offering various heat transfer properties. Generally used in processes where sealing is crucial, as the name suggests, the plates in these exchangers are brazed together. With few moving parts, they have a structure that is more resistant to corrosion, pressure, and temperature. The general structure of brazed exchangers with three different types of plates that can be chosen according to the need is as shown in the diagram below.
Heat exchangers are devices that facilitate energy transfer between fluids at different temperatures. Brazed heat exchangers are compact exchangers produced by fixing the plates together using a special brazing material. This design offers excellent sealing and durability under high pressure and temperature conditions.
Design Features
Brazed heat exchangers usually use plates made of stainless steel or other corrosion-resistant materials. The space between the plates is filled with solder, creating a locked structure. This structure allows fluids to move through very narrow channels between the plates, which increases heat transfer efficiency. Operating
Principle In brazed heat exchangers, heat transfer occurs as hot and cold fluids flow in opposite directions along the plates. The fluids transfer heat as they pass over the plate surfaces. This method provides maximum heat transfer surface area and thus a high heat transfer coefficient.
Application Areas
Brazed heat exchangers are commonly used in HVAC systems, cooling systems, heat pumps, and various industrial processes. These devices can be effectively used even in compact spaces due to their compact size and high efficiency.
Advantages
High Efficiency: Brazed heat exchangers provide high efficiency in heat transfer due to their narrow channels and large surface area.
Compact Design: Their compact size takes up less space and makes installation easy.
Low Maintenance Requirement: The brazed structure minimizes the risk of leaks and reduces maintenance requirements.
Durability: Offers excellent durability under high pressure and temperature conditions.
Limitations
The main limitations of brazed heat exchangers include their difficulty to repair and sensitivity to certain chemicals. Therefore, appropriate material selection and design verification are important before use.
Brazed heat exchangers play a significant role in modern heat transfer applications. These devices offer high efficiency, compact structure, and low maintenance requirements, making them ideal solutions for many systems. Appropriate design and material selection maximize the performance and reliability of these exchangers.
Advanced Design and Various Applications
Extended Design Features
Brazed heat exchangers stand out with various design features. These designs can include multiple plate arrangements and different plate geometries. The shape and depth of the grooves on the plate surfaces increase the turbulence of the fluid, optimizing heat transfer. Additionally, the arrangement of these plates ensures that the fluid remains in contact with the plate surfaces for a longer time, enhancing heat transfer efficiency.
Material Selection and Applications
Material selection for brazed heat exchangers varies depending on the chemical, thermal, and mechanical requirements of the application. While stainless steel is generally preferred for common use, nickel or titanium-based alloys can be used for more aggressive environments. These materials enhance the corrosion resistance and mechanical strength of the heat exchanger, extending its life.
Detailing the Application Areas
Brazed heat exchangers are used in various fields such as food processing, biotechnology, and the pharmaceutical industry. Particularly, these exchangers are preferred during the processing of dairy products or the sterilization of biological materials. Additionally, they are effective in energy recovery systems and waste heat utilization applications. In these systems, heat exchangers use waste heat to generate additional energy, increasing energy efficiency.
Technological Developments and Innovations
Technological advancements continuously improve the design and performance of brazed heat exchangers. For instance, in recent years, the use of nanotechnology in developed coating techniques has increased the efficiency of heat transfer surfaces. Additionally, smart sensors and automation technologies are integrated to monitor and optimize the operations of heat exchangers, thus controlling system efficiency in real-time.
Conclusion and Future Perspectives
Brazed heat exchangers have become indispensable in industrial and commercial applications due to their high heat transfer efficiency, compact structure, durability, and low maintenance needs. In the future, further development of this technology and the use of environmentally friendly materials are expected to provide superior solutions in terms of sustainability and performance. These advancements will enable the use of heat exchangers in a broader range of applications and play a critical role in enhancing energy efficiency."
Oil Cooling Applications;
Brazed exchangers are the type of exchanger that offers the best performance in the most efficient manner for oil cooling applications. Brazed exchangers should be the primary choice for oil cooling processes unless the capacity is very high or the temperature exceeds the working limits of these exchangers. However, tubular exchangers can also be chosen under these specified conditions. Efficient, durable, and compact, MIT Brazed Heat Exchangers provide high and efficient performance and are covered by a 2-year warranty by Ekin Industrial.
Plates and connections are made from AISI 316 standard stainless steel and are brazed with 1.4401 copper in a vacuum. Special design plates that create the necessary turbulent flow for effective heat transfer have a high level of mechanical strength.
Media
- Water glycol (coolant)
- Operating fluid
- Water
- Oil
Contamination
- Particulate matter should be less than 10 mg per liter.
- Particle size < 0.6 mm. (spherical)
- Fiber-like particles may cause rapid pressure drop.
Temperature Range
- (-196°C / 200°C) (freezing and boiling points should be considered)
Pressure
- Maximum working pressure: 30 bar
- Maximum test pressure: 45 bar
Corrosion
- At pH 7, see the limits below
- Chlorine-free, CL2 < 0.5 ppm
- With chlorine ions, CL < 700 ppm (at 20°C), < 200 ppm (at 50°C)
Other Limits
- ph 7 - 10
- Sulfate SO4 2- < 100 ppm
- [H CO3 -] / [SO4 2-] > 1
- Ammonia, NH3 < 10 ppm
